LD Systems MG2IK1W Installation Kit For MAUI G2 Column
Streamlining MAUI installations is a breeze with this low-profile wall mount kit. It contains a wall plate and slim hook-in bracket that holds the column. They require an installation height of 15 mm only putting the column nearly flush to the wall. The plate and bracket are made of heavy-gauge steel and available in black (LDMG2IK1) or white (LDMG2IK1W) powder coating finish. The kit also includes two adapters for the system’s multipin connectors which provide loudspeaker and terminal block connectors to hook up the column and sub.
Specifications
- Wall mounted installation kit for Maui G2 Column arrays
- Suits both Maui 11G2 & Maui 28G2 models
- Sleek and professional design with ultra low profile
- Easy to install with all components included
- Includes 2 terminal adapters with connection cable
- Made from high quality materials
Technical Information
| Product number: | LDMG2IK1W |
|---|---|
| Product type: | PA Loudspeakers Accessories |
| Weight: | 0.001kg |
| Material Wall Mount Bracket: | steel |
| Surface Wall Mount Bracket: | powder coated |
| Colour Wall Mount Bracket: | white |
| Mar. Load Wall Mount Bracket: | 12kg |
| Dimensions Wall Mount Bracket (W x H x D): | 75mm x 810mm x 15mm |
| Weight Wall Mount Bracket: | 1.5kg |
| Features Column Adapter: | Speakon compatible, M20 Thread, Terminal Block Connector |
| Material Column Adapter: | aluminium |
| Surface Column Adapter: | powder coated |
| Colour Column Adapter: | white |
| Dimensions Column Adapter (B x H x T): | 100mm x 65mm x 105mm |
| Weight Column Adapter: | 0.7kg |
| Features Subwoofer Adapter: | Speakon compatible, Terminal Block Connector |
| Material Subwooferadapter: | aluminium |
| Subface Subwoofer Adapter: | powder coated |
| Colour Subwoofer Adapter: | white |
| Dimensions Subwoofer Adapter (W x H x D): | 100mm x 105mm x 105mm |
| Weight Subwoofer Adapter: | 0.5kg |
| Colour Terminal Block Connector: | green |
| Features Terminal Block Connector: | 4 pole |
| Quantity Terminal Block Connector: | 2pcs. |
